Top Alloy 254 SMO Distributor in India, Get discounted SMO 254 Prices by ordering now
Table of Content
SMO 254 sheet, plate, and coil are premium-grade austenitic stainless steel products known for their outstanding corrosion resistance and mechanical strength. These materials are well-suited for environments exposed to chlorides, acidic compounds, and seawater. Composed of high levels of nickel, chromium, molybdenum, copper, and nitrogen, it provides excellent protection against localized corrosion, including pitting and crevice attack. Preston Pipes & Alloys supplies these products, with exacting chemical composition and physical properties that align with international standards. With impressive tensile and yield strength, combined with good ductility, these materials are ideal for high-demand applications.
These components are highly appreciated for their structural integrity, accurate dimensions and refined surface texture. It can be used for any kind of heavy-duty applications due to its capacity to withstand high stress and retain its shape under load. Even in harsh conditions, the products long lifespan is ensured by the robust design and inherent anti-corrosive nature. These plates are therefore widely used in various industries, including power generation systems, pulp and paper processing, chemical manufacturing, desalination plants, marine engineering, and oil and gas exploration.
In order to meet various project requirements, SMO 254 plates and sheets are produced in different sizes and finishes. Options include thicknesses ranging from 3 to 150 mm, widths ranging from 1220 to 4200 mm and lengths ranging from 5000 to 18000 mm. Both hot-rolled, and cold-drawn manufacturing techniques are used. International Standards include ASTM, DIN, and JIS. Each plate is tested thoroughly using methods like PMI, NDT, hydrostatic, hardness, and flaring tests to verify performance.
Before dispatch, all products undergo thorough inspection and quality assurance testing. This testing includes raw material certification, radiography testing, and third-party certification. Each product is carefully packaged against damage during transport so that it reaches the customer in pristine condition. Traceability is assured from manufacturing to delivery, as full documentation is provided with every shipment. With a huge inventory of sheets, coils and plates, we offer timely availability, and speedy completion of customer orders.
Leading SMO 254 plates Manufacturer and Supplier from Mumbai, India
| Specification | ASTM A240 / ASME SA240 |
| Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Size Range | Cold rolled Grades 254 SMO Plates 0.5-6.4 mm Hot rolled Grades 254 SMO Plates 3.0–10.0 mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Thickness | 0.3 mm to 120 mm |
| Finish | 2B, 2D, BA NO (8), Cold rolled Plates (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
Size chart of Alloy 254 6 Mo Sheet
| Nominal Size Thickness (inches) |
Weight (lb/ft 2 ) |
| 3/16 | 7.65 |
| 1/4 | 10.2 |
| 5/16 | 12.8 |
| 3/8 | 15.3 |
| 7/16 | 17.9 |
| 1/2 | 20.4 |
| 9/16 | 22.9 |
| 5/8 | 25.5 |
| 11/16 | 28.1 |
| 3/4 | 30.6 |
| 13/16 | 33.2 |
| 7/8 | 35.7 |
| 1 | 40.8 |
| 1 1/8 | 45.9 |
| 1 1/4 | 51.0 |
| 1 3/8 | 56.1 |
| 1 1/2 | 61.2 |
| 1 5/8 | 66.3 |
| 1 3/4 | 71.4 |
| 1 7/8 | 76.5 |
| 2 | 81.6 |
| 2 1/8 | 86.7 |
| 2 1/4 | 91.8 |
| 2 1/2 | 102 |
| 2 3/4 | 112 |
| 3 | 122 |
| 3 1/4 | 133 |
| 3 1/2 | 143 |
| 3 3/4 | 153 |
| 4 | 163 |
| 4 1/4 | 173 |
| 4 1/2 | 184 |
| 5 | 204 |
| 5 1/2 | 224 |
| 6 | 245 |
| 6 1/2 | 265 |
| 7 | 286 |
| 7 1/2 | 306 |
| 8 | 326 |
| 9 | 367 |
| 10 | 408 |
Alloy 254 6 Mo Sheet
Werkstoff Nr. 1.4547 Strip
ASTM A240 UNS S31254 Perforated Sheet
254 SMO 6 Moly Chequered Plate
Aisi 254 SMO Coil
6 Moly Foil
SMO 254 Shim Sheet
Alloy 254 SMO Hot Rolled Plate
Click to order high quality SMO 254 Sheet, Plate, Coil!
High quality SMO 254 sheets & plates at your doorstep, View SMO 254 material specification, 254 SMO material data sheet
| Ni | Mo | C | Mn | Cr | Si | Cu | S | Fe | P |
| 17.5 - 18.5 | 6 - 6.5 | 0.02 max | 1 max | 19.5 - 20.5 | 0.8 max | 0.5 - 1 | 0.01 max | - | 0.03 max |
| UNS Designation & International Equialent for SMO 254 Plates | |||||||||
| Type | UNS | WNR. | JIS | EN | BS | AFNOR | GOST | ||
| SMO 254 | S31254 | 1.4547 | SUS312L | X1CrNiMoCuN20-18-7 | – | Z1 CNDU 20.18.06AZ | – | ||
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SMO 254 | 8.0 g/cm3 | 1320-1390°C | MPa – 650 | MPa – 300 | 35 % |
