Stainless Steel 904L Round Bar Supplier


Stainless Steel 904L Round Bar is a low-carbon, high-alloy austenitic stainless steel bar designed for corrosion resistance in harsh environments. Known for its excellent toughness and strength, this grade combines key elements like carbon, manganese, silicon, phosphorus, sulfur, chromium, molybdenum, nickel and copper to deliver solid mechanical performance. The material has a density of 7.95 g/cm³, a melting point of 1350°C, a tensile strength of 71,000 psi, and a yield strength of 32,000 psi. Preston Pipes & Alloys is a reliable supplier of 904L stainless steel round bars, producing high-quality materials in accordance with global dimension standards such as EN, DIN, JIS, ASTM, BS, ASME, and AISI.


The 904L round bar performs reliably in extreme temperatures and corrosive conditions. It handles sulfuric acid processing safely and resists stress corrosion cracking. DIN 1.4539 flat bar performs well in environments ranging from 35°C to 40°C. It is widely used in acid processing, gas washing systems, pulp and paper production, and oil and gas facilities. The strength and chemical stability of ASTM B649 type 904L rod make it a good fit for heavy-duty industrial operations where high resistance is required over time.


SS 904L Round Bar

We offer Stainless Steel 904L Round Bars in sizes ranging from 14mm to 300mm and lengths from 1 to 6 meters, including custom cuts. Thickness goes up to 6000mm long. Forms include round, square, hex, billet, ingot, and forged types. The bars are produced through forging or rolling, ensuring durability and performance. Finishes include polished, rough turned, and NO.4, depending on the usage needs. Our UNS N08904 round bar is suitable for structural and pressure applications.


Every 904L round bar goes through quality checks from surface and end finish inspections to dimension and toughness tests. Products meet key standards like ASTM A276 / A479 and ASME SA276 / A479. Each bar is packed carefully to maintain its finish and strength during transport. Available in different shapes, sizes, and specifications, our bars are ready for high-demand environments. For reliable supply and consistent quality, choose our 904L stainless steel round bars.

Stainless Steel 904L Round Bar Specification

Specifications ASTM A276, ASME SA276 / ASTM A479 ASME SA479
Standard EN, DIN, JIS, ASTM, BS, ASME, AISI
SS 904L Round Bars Outside Diameter in the range of 4mm to 500mm
SS 904L Bright Bars Outside Diameter in the range of 4mm to 100mm
SS 904L Hex Bars 18mm – 57mm (11/16″ to 2-3/4″)
SS 904L Square Bars 18mm – 47mm (11/16″ to 1-3/4″)
SS 904L Flat Bars 1/2” to 10” in thickness range of 2mm to 150mm
Finish Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish
Length 1 to 6 Meters, Custom Cut Lengths
Form Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc.

Common Type of Stainless Steel 904L Round Bar

SS 904L Hex Bar

SS 904L Hex Bar

SS 904L Bright Bar

SS 904L Bright Bar

SS 904L Cold Rolled Bar

SS 904L Cold Rolled Bar

SS 904L Flat Bar

SS 904L Flat Bar

SS 904L Square Bar

SS 904L Square Bar

SS 904L Rectangular Bar

SS 904L Rectangular Bar

SS 904L Polished Round Bar

SS 904L Polished Round Bar

SS 904L Hollow Bar

SS 904L Hollow Bar


Contact Preston Pipes and Alloys for best offer & competitive
quotation of Stainless Steel 904L Round Bar

Stainless Steel 904L Round Bar Chemical Composition

Grade C Mn Si P S Cr Mo Ni Cu
SS 904L 0.020 max 2 max 1 max 0.040 max 0.030 max 19.0–23.0 4.0–5.0 max 23.00–28.00 1.0–2.0

Stainless Steel 904L Round Bar Mechanical Properties

Density Melting Point Tensile Strength Yield Strength (0.2% Offset) Elongation
7.95 g/cm3 1350 °C (2460 °F) Psi – 71,000 , MPa – 490 Psi – 32,000 , MPa – 220 35%

Stainless Steel 904L Round Bar Equivalent Material

STANDARD WERKSTOFF NR. UNS JIS BS KS AFNOR EN
SS 904L 1.4539 N08904 SUS 904L 904S13 STS 317J5L Z2 NCDU 25-20 X1NiCrMoCu25-20-5

Stainless Steel 904L Round Bar Weight Chart

Diameter Weight Chart Dia Weight Chart
(mm) per metre (kg) (in) per metre (kg)
3mm 0.06 1/8" 0.06
4mm 0.10 3/16" 0.14
5mm 0.16 1/4" 0.25
6mm 0.22 5/16" 0.39
7mm 0.30 3/8" 0.56
8mm 0.40 7/16" 0.77
10mm 0.62 1/2" 1.00
12mm 0.89 9/16" 1.22
14mm 1.22 5/8" 1.56
15mm 1.40 11/16" 1.89
16mm 1.59 3/4" 2.25
18mm 2.01 7/8" 3.07
20mm 2.48 1" 4.03
22mm 3.00
24mm 3.57
25mm 3.88

Industrial Application of Stainless Steel 904L Round Bar
