ASTM B575 Hastelloy C276 Sheet, Alloy C276 Plate Suppliers in Mumbai, India
Table of Content
Hastelloy C276 Plate, Sheet, and Coil are flat-rolled products composed of a nickel-molybdenum-chromium alloy with added iron and cobalt. Plates are thicker and better suited for high-stress applications, whereas Hastelloy C276 Sheet is thinner and used in situations requiring flexibility. Hastelloy C276 Coil is a continuous roll form for automated fabrication. Their composition includes nickel, molybdenum, chromium, iron, cobalt, carbon, manganese, silicon, sulfur, and phosphorus. Preston Pipes & Alloys is a trusted Hastelloy C276 plate supplier, known for producing high-quality products in custom sizes and finishes.
ASTM B575 UNS N10276 Hastelloy C276 Sheet provide excellent mechanical strength and corrosion resistance. They maintain strong performance even at elevated temperatures between 649°C to 760°C. Alloy C276 Plate show high tensile strength, yield strength and good elongation. Hastelloy C276 Sheet offers higher tensile properties than the plate variant. They also show great resistance to pitting, stress corrosion cracking, and oxidizing agents. Each product is made using advanced processes like hot rolling, annealing and surface finishing to ensure long-term durability.
DIN 2.4819 Plate is used in seawater systems, air pollution control, pharmaceuticals, and metal processing. The Alloy C276 sheet sizes range from 0.02 to 4.0 mm in thickness, widths from 900 to 2400 mm, and lengths up to 12000 mm. Plate sizes come in thicknesses from 4.5 to 100 mm. Hastelloy C276 Coils are available in 2.5 to 10.0 mm thickness and widths of 610 to 2000 mm. Popular surface finishes include brushed, glossy, sandblasted and mirror. These sheets and plates work well in corrosive environments.
Hastelloy C276 Sheet and Plate go through strict quality checks and standard tests before shipping. Tests include visual inspection, chemical analysis, mechanical testing, and third-party inspections. Products are packed securely and meet ASTM B575 / ASME SB575 standards. Certified test reports are provided as required. We offer products in custom surface finishes, end finishes, sizes, shapes, and thickness options. Get high-performance plates that meet both domestic and international quality standards.
Hastelloy Alloy C276 Coil at Affordable Prices, Stockist of UNS N10276 Shim Sheet, ASME SB575 Hastelloy C276 Strip
| Standard | ASTM B575 / ASME SB575 |
| Material Grade | Hastelloy C276 (UNS N10276, W.Nr. 2.4819) |
| Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness Range | 3/16″ (4.8 mm) to 2-1/2″ (63.5 mm) (custom available) |
| Length | 2000 mm to 6000 mm (cut-to-size available) |
| Finish | Hot rolled, cold rolled, 2B, No.1, No.4, BA, hairline, polished |
| Hardness | Soft, hard, half hard, spring hard (as required) |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle) |
| Packing | Packed in Wooden Boxes, Bubble wraps, Steel Strips Bundled, or as per Customers Requests |
| Testing and Documents | Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, Destructive Test Report, Non Destructive Test Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports |
| Size (Inch) | Size (mm) |
| 3/16" | 4.8 mm |
| 1/4" | 6.3 mm |
| 3/8" | 9.5 mm |
| 1/2" | 12.7 mm |
| 5/8" | 15.9 mm |
| 3/4" | 19 mm |
| 1" | 25.4 mm |
| 1 1/4" | 31.8 mm |
| 1 1/2" | 38.1 mm |
| 1 3/4" | 44.5 mm |
| 2" | 50.8 mm |
| 2 1/2" | 63.5 mm |
Hastelloy C276 Sheet Metal
ASTM B575 Type C276 Perforated Sheet
Hastelloy C276 Chequered Plate
Hastelloy C276 Plain Sheet
Hastelloy C276 Cold Rolled Sheet
UNS N10276 Hot Rolled Plate
Hastelloy C276 Strip
Hastelloy C276 Coil
Hastelloy C276 Foil
Hastelloy C276 Shim Sheet
Hastelloy C276 Shim Stock
Get in touch with us for the best deal on Hastelloy C276 Sheet, Plate and Coil
| Element | Content (%) |
| (Ni) Nickel | Remainder |
| (Mo) Molybdenum | 15.0 to 17.0 |
| (Cr) Chromium | 14.5 to 16.5 |
| (Fe) Iron | 4.0 to 7.0 |
| (W) Tungsten | 3.0 to 4.5 |
| (Co) Cobalt | 2.5 max |
| (Mn) Manganese | 1.0 max |
| (V) Vanadium | 0.35 max |
| (Si) Silicon | 0.08 max |
| (P) Phosphorus | 0.04 max |
| (S) Sulfur | 0.03 max |
| (C) Carbon | 0.010 max |
|
0.2% Offset |
Strength |
in 2" |
|
||
| psi (min.) | (MPa) | psi (min.) | (MPa) | % (min.) | (max.) |
| 41,000 | 283 | 100,000 | 690 | 40 | 100 Rockwell B |
| Property | Imperial Units | Metric Units |
| Density | 0.321 lbs/in³ | 8.89 g/cm³ |
| Specific Heat | 0.102 BTU/lb-°F (70°F) | 427 J/kg-K (20°C) |
| Modulus of Elasticity | 29.8 × 10⁶ psi | 205.0 GPa |
| Thermal Conductivity (212°F / 100°C) | 67 BTU/hr/ft²/ft/°F | 9.8 W/m-K |
| Melting Range | 2415 – 2500°F | 1325 – 1370°C |
| Electrical Resistivity | 51 μΩ·in at 75°C | 1.30 μΩ·cm at 24°C |
| °F | °C | in/in/°F | cm/cm°C |
| 200 | 93 | 6.8 × 10⁻⁶ | 12.24 × 10⁻⁶ |
| 400 | 204 | 7.0 × 10⁻⁶ | 12.60 × 10⁻⁶ |
| 600 | 316 | 7.2 × 10⁻⁶ | 12.96 × 10⁻⁶ |
| 800 | 427 | 7.4 × 10⁻⁶ | 13.32 × 10⁻⁶ |
| 1000 | 538 | 7.8 × 10⁻⁶ | 14.0 × 10⁻⁶ |
| 1200 | 649 | 8.2 × 10⁻⁶ | 14.8 × 10⁻⁶ |
| 1400 | 760 | 8.5 × 10⁻⁶ | 15.3 × 10⁻⁶ |
| 1600 | 871 | 8.8 × 10⁻⁶ | 15.8 × 10⁻⁶ |
| 1700 | 927 | 9.0 × 10⁻⁶ | 16.2 × 10⁻⁶ |
|
|
|||
| Sulfuric Acid | Good | Organic Acids | Excellent |
| Phosphoric Acid | Good | Strong Alkalis | Excellent |
| Hydrochloric Acid | Good | Reducing Salts | Excellent |
| Hydrofluoric Acid | Excellent | Oxidizing Salts | Not recommended |
| Nitric Acid | Not Recommended | Seawater | Good |
| Chemical Environment | Concentration | Temperature | Maximum Corrosion Rate (mpy) | Performance |
| Hydrochloric Acid | 10% | 70°F (21°C) | <1 | Excellent resistance. Performance is superior to most other metals. |
| Sulfuric Acid | 10% | 100°F (38°C) | <1 | Outstanding resistance in non-oxidizing sulfuric acid solutions. |
| Acetic Acid | 100% | Boiling | <1 | Excellent resistance in all concentrations and temperatures. |
| Phosphoric Acid | 85% | 100°F (38°C) | <0.1 | Exceptional resistance, making it ideal for phosphoric acid service. |
| Wet Chlorine Gas | - | Ambient & Higher | <0.1 | One of the few alloys that can handle wet chlorine gas effectively. |
| Sour Gas (Oil & Gas) | H₂S, CO₂, Cl⁻ | High Temp/Pressure | Excellent | Highly resistant to chloride-induced stress corrosion cracking (SCC) and pitting. |
| Seawater | - | Ambient & Higher | <0.1 | Superior resistance to pitting and crevice corrosion in stagnant or slow-moving seawater. |
| Bleach (Sodium Hypochlorite) | - | Ambient | <0.1 | Resists the highly corrosive conditions in bleach and chlorination systems. |
| Formic Acid | 10% | Boiling | <1 | Excellent resistance in all concentrations. |
| Chlorine Dioxide | All | All | Excellent | A premier material for pulp and paper bleaching applications. |
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN | OR |
| Hastelloy C276 | 2.4819 | N10276 | NW 0276 | ХН65МВУ | NiMo16Cr15W | ЭП760 |
