Stainless steel 446 pipes are high-chromium ferritic alloys with excellent heat and corrosion resistance. These pipes work well in environments with high temperatures, scaling, and oxidation. Preston Alloys, a reputable 446 stainless steel pipe manufacturer, provides high-quality pipes with consistent performance. Grade 446 contains elements such as carbon, manganese, silicon, phosphorus, sulfur, chromium, nickel, and nitrogen. It remains stable between 1500°F and 2100°F. While the elevated temperature strength is lower, its corrosion resistance makes it ideal for heat-based systems. With solid mechanical and physical properties, these pipes are dependable in demanding setups.
446 stainless steel pipes have a minimum tensile strength of 485 MPa and a yield strength of 275 MPa, ensuring consistent performance under stress. SS 446 has a density of 7750 kg/m³ and excellent thermal conductivity at high temperatures. These pipes are resistant to oxidation and corrosion under heat, making them ideal for long-term use. AISI 446 pipe is commonly used in oil burners, furnace components, soot blowers, and heat exchangers. Its durability extends to glass moulds and kiln liners. Uns S44600 seamless pipe is also used in the oil and gas, petrochemical, construction, and general industrial sectors.
We offer ASTM A268 TP446 pipes in both round and square forms. Round pipes come in outer diameters ranging from 6mm to 710mm, and square pipes range from 10x10mm to 400x400mm. Wall thickness from 1.0mm to 50mm for round and up to 20mm for square types. Available in seamless, welded, ERW, EFW, and fabricated types with options like 100% X-Ray welded. Lengths range from 2 to 12 meters. Finishes include annealed & pickled, hot rolled No.1 mill finish, polished, matte, and grit finishes like 240, 400, and 500. We meet different project needs with reliable dimensions and finishes.
Quality tests are performed on all SS 446 pipes to ensure their performance and consistency. We follow the ASTM A312, ASME SA312, ASTM A213, ASME SA213, and ASTM A268/ASME SA268 standards. Pipes are securely packed to avoid damage during transportation. As a 446 stainless steel pipe supplier, we provide pipes in a variety of sizes and shapes to meet our customers' needs. 446 stainless steel pipe price depends on size, type, and finish. Reach out to get a quote or learn more about our product range.
| Specifications | ASTM A/ASME SA213/A249/A269/A312/A358 CL. I to V ASTM A789/A790 |
| Dimensions | ASTM, ASME and API |
| Standards | GB/T 14975-2002, GB/T 14976-2002, GB 13296-91, API, ASTM A213, ASTM A312, ASTM A269, JIS G3459, JIS G3463, JIS G3448, DIN17458 |
| 446 Pipes & Tubes | 1/2" NB - 24" NB |
| ERW 446 Pipes & Tubes | 1/2" NB - 24" NB |
| EFW 446 Pipes & Tubes | 6" NB - 100" NB |
| Tubing Size | 1/8″ NB TO 30″ NB IN |
| Specialized in | Large Diameter Size |
| Schedule | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Type | Seamless / ERW / Welded / Fabricated / LSAW Pipes |
| Form | Round, Square, Rectangular, Hydraulic Etc |
| Length | Single Random, Double Random & Cut Length. |
| End | Plain End, Beveled End, Threaded |
| PIPE SIZE |
OD IN INCHES |
A.S.A. Pipe Schedules | |||||||||||||||
| 5s | 5 | 10s | 10 | 20 | 30 | 40s & Std. |
40 | 60 | 80s & E.H. |
80 | 100 | 120 | 140 | 160 | DBL E.H. |
||
| 1/8 | .405 | .035 .1383 |
.049 .1863 |
.049 .1863 |
.068 .2447 |
068 .2447 |
0.95 .3145 |
0.95 .3145 |
|||||||||
| 1/4 | .540 | .049 .2570 |
.065 .3297 |
.065 .3297 |
.088 .4248 |
088 .4248 |
.119 .5351 |
.119 .5351 |
|||||||||
| 3/8 | .675 | .049 .3276 |
.065 .4235 |
.065 .4235 |
.091 .5676 |
.091 .5676 |
.126 .7338 |
.126 .7338 |
|||||||||
| 1/2 | .840 | .065 .5383 |
.065 .5383 |
.083 .6710 |
.083 .6710 |
.109 .8510 |
.109 .8510 |
.147 1.088 |
.147 1.088 |
.187 1.304 |
.294 1.714 |
||||||
| 3/4 | 1.050 | .065 .6838 |
.065 .6838 |
.083 .8572 |
.083 .8572 |
.113 1.131 |
.113 1.131 |
.154 1.474 |
.154 1.474 |
.218 1.937 |
.308 2.441 |
||||||
| 1 | 1.315 | .065 .8678 |
.065 .8678 |
.109 1.404 |
.109 1.404 |
.133 1.679 |
.133 1.679 |
.179 2.172 |
.179 2.172 |
.250 2.844 |
.358 3.659 |
||||||
| 1-1/4 | 1.660 | .065 1.107 |
.065 1.107 |
.109 1.806 |
.109 1.806 |
.140 2.273 |
.140 2.273 |
.191 2.997 |
.191 2.997 |
.250 3.765 |
.382 5.214 |
||||||
| 1-1/2 | 1.900 | .065 1.274 |
.065 1.274 |
.109 2.085 |
.109 2.085 |
.145 2.718 |
.145 2.718 |
.200 3.631 |
.200 3.631 |
.281 4.859 |
.400 6.408 |
||||||
| 2 | 2.375 | .065 1.604 |
.065 1.604 |
.109 2.638 |
.109 2.638 |
.154 3.653 |
.154 3.653 |
.218 5.022 |
.218 5.022 |
.343 7.444 |
.436 9.029 |
||||||
| 2-1/2 | 2.875 | .083 2.475 |
.083 2.475 |
.120 3.531 |
.120 3.531 |
.203 5.793 |
.203 5.793 |
.276 7.661 |
.276 7.661 |
.375 10.01 |
.552 13.70 |
||||||
| 3 | 3.500 | .083 3.029 |
.083 3.029 |
.120 4.332 |
.120 4.332 |
.216 7.576 |
.216 7.576 |
.300 10.25 |
.300 10.25 |
.437 14.32 |
.600 18.58 |
||||||
| 3-1/2 | 4.000 | .083 3.472 |
.083 3.472 |
.120 4.973 |
.120 4.973 |
.226 9.109 |
.226 9.109 |
.318 12.51 |
.318 12.51 |
.636 22.85 |
|||||||
| 4 | 4.500 | .083 3.915 |
.083 3.915 |
.120 5.613 |
.120 5.613 |
.237 10.79 |
.237 10.79 |
.281 12.66 |
.337 14.98 |
.337 14.98 |
.437 19.01 |
.531 22.51 |
.674 27.54 |
||||
| 4-1/2 | 5.000 | .247 12.53 |
.355 17.61 |
.710 32.53 |
|||||||||||||
| 5 | 5.563 | .109 6.349 |
.109 6.349 |
.134 7.770 |
.134 7.770 |
.258 14.62 |
.258 14.62 |
.375 20.78 |
.375 20.78 |
.500 27.04 |
.625 32.96 |
.750 38.55 |
|||||
| 6 | 6.625 | .109 7.585 |
.109 7.585 |
.134 9.290 |
.134 9.290 |
.280 18.97 |
.280 18.97 |
.432 28.57 |
.432 28.57 |
.562 36.39 |
.718 45.30 |
.864 53.16 |
|||||
| 7 | 7.625 | .301 23.57 |
.500 38.05 |
||||||||||||||
| NPS | OD | SCH 5S | SCH 10S | SCH 40S | SCH 80S |
| 1/4 | 13.72 | – | 1.65 | 2.24 | 3.02 |
| 3/8 | 17.15 | – | 1.65 | 2.31 | 3.2 |
| 1/2 | 21.34 | 1.65 | 2.11 | 2.77 | 3.73 |
| 3/4 | 26.67 | 1.65 | 2.11 | 2.87 | 3.91 |
| 1 | 33.4 | 1.65 | 2.77 | 3.38 | 4.55 |
| 1.25 | 42.16 | 1.65 | 2.77 | 3.56 | 4.85 |
| 1.5 | 48.26 | 1.65 | 2.77 | 3.68 | 5.08 |
| 2 | 60.33 | 1.65 | 2.77 | 3.91 | 5.54 |
| 2.5 | 73.03 | 2.11 | 3.05 | 5.16 | 7.01 |
| 3 | 88.9 | 2.11 | 3.05 | 5.49 | 7.62 |
| 3.5 | 101.6 | 2.11 | 3.05 | 5.74 | 8.08 |
| 4 | 114.3 | 2.11 | 3.05 | 6.02 | 8.56 |
| 5 | 141.3 | 2.77 | 3.4 | 6.55 | 9.53 |
| 6 | 168.28 | 2.77 | 3.4 | 7.11 | 10.97 |
| 8 | 219.08 | 2.77 | 3.76 | 8.18 | 12.7 |
| 10 | 273.05 | 3.4 | 4.19 | 9.27 | 12.7 |
| 12 | 323.85 | 3.96 | 4.57 | 9.53 | 12.7 |
| 14 | 355.6 | 3.96 | 4.78 | 9.53 | 12.7 |
| 16 | 406.4 | 4.19 | 4.78 | 9.53 | 12.7 |
| 18 | 457.2 | 4.19 | 4.78 | 9.53 | 12.7 |
| 20 | 508 | 4.78 | 5.54 | 9.53 | 12.7 |
| 22 | 558.8 | 4.78 | 5.54 | – | – |
| 24 | 609.6 | 5.54 | 6.35 | 9.53 | 12.7 |
| 26 | 660.4 | – | – | – | – |
| 28 | 711.2 | – | – | – | – |
| 30 | 762 | 6.35 | 7.92 | – | – |
| Properties | Metric | Imperial |
| Thermal expansion co-efficient (@0-100°C/32-212°F) | 10.4 µm/m°C | 5.78 µin/in°F |
| Thermal conductivity | 21.6 W/mK | 150 BTU in/hr.ft².°F |
| NPS | ASTM A312 TP446 OD Tolerance | |||
| + | – | |||
| inch | mm | inch | mm | |
| 1/8~1 1 /2 > 1 1 /2~4 > 4~8 > 8~18 > 18~26 > 26~34 > 34~48 |
1/64(0.015) 1/32(0.031) 1/16(0.062) 3/32(0.093) 1/8(0.125) 5/32(0.156) 3/16(0.187) |
0.4 0.8 1.6 2.4 3.2 4.0 4.8 |
1/32(0.031) 1/32(0.031) 1/32(0.031) 1/32(0.031) 1/32(0.031) 1/32(0.031) 1/32(0.031) |
0.8 0.8 0.8 0.8 0.8 0.8 0.8 |
| NPS | ASTM A312 TP 446 WT Tolerance, % | |
| + | – | |
| 1/8-2 1 /2 | 20.0 | 12.5 |
| 3~18, t/D≤ 5% | 22.5 | 12.5 |
| 3~18, t/D> 5% | 15.0 | 12.5 |
| ≥ 20, welded | 17.5 | 12.5 |
| ≥ 20, seamless, t/D≤ 5% | 22.5 | 12.5 |
| ≥ 20, seamless, t/D> 5% | 15.0 | 12.5 |
Stainless Steel 446 Seamless Pipe
Stainless Steel 446 Welded Pipe
Stainless Steel 446 ERW Pipe
Stainless Steel 446 EFW Pipe
Stainless Steel 446 Round Pipe
Stainless Steel 446 Square Pipe
Stainless Steel 446 Rectangular Pipe
Stainless Steel 446 Polished Pipe
Get in touch with us for the best deal on 446 Stainless Steel Pipes
| Iron, Fe | Chromium, Cr | Manganese, Mn | Silicon, Si | Nickel, Ni | Carbon, C | Phosphorous, P | Sulfur, S |
| 73 | 23.0 – 27.0 | 1.50 | 1.0 | 0.25 | 0.20 | 0.040 | 0.030 |
| Properties | Metric | Imperial |
| Tensile strength | 550 MPa | 79800 psi |
| Yield strength (@strain 0.200%) | 345 MPa | 50000 psi |
| Elastic modulus | 200 GPa | 29000 ksi |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at break | 20% | 20% |
| Hardness, Brinell (estimated from Rockwell B) | 159 | 159 |
| Hardness, Knoop (estimated from Rockwell B) | 173 | 173 |
| Hardness, Rockwell A (estimated from Rockwell B) | 51.1 | 51.1 |
| Hardness, Rockwell B | 83 | 83 |
| Hardness, Vickers (estimated from Rockwell B) | 159 | 159 |
