Low Temperature Grade 1/3/4/6/7/8/9/10/11 Pipes Stockist in Mumbai India.
ASTM A333 Low Temp. Carbon Steel Grade 1 Seamless, Welded Pipes
ASTM A333 LTCS Gr 6 ERW Pipes Stockist and Supplier in Mumbai India.
Preston Pipes and Alloys supply the Low Temperature Carbon steel Seamless Pipes. It covers seamless and welded steel pipe for use at cold temperatures. This grade has similar properties as alloy steels. We have a large stockpile of these pipes in various specifications, standards, dimensions, and shapes. Customers also can demand any specific requirement as per their applications.
LTCS Seamless Pipes resists chloride environments, sulfide stress corrosion. This alloy has the molybdenum content that enables pipes to withstand at corrosive environments. In exposure to temperatures of 1000F to 1400F, these shows improved strength and decreased ductility with no embrittle phases. These pipes are roughly double in the strength compare to standard steel pipes. The composition of low Temperature CS Seamless Pipes has improved over many years, results these provides excellent corrosion resistance. However, this alloy forms a dual form.
These pipes are generally suitable for use at the temperature above 300 degrees as it suffers from precipitation. These pipes are fabricated with the automated machinery to get craving dimensions and uniform design. These are well treated with metal treatment process endorse strength and toughness. Sturdy finish and maintained structure are supported by industrial finishing process also the extra layer of protection is developed by the coatings.
All the pipes here we exported are tested under the model of national and international standards. the testing we perform is the radiographic test, pitting corrosion test, hardness test, tensile test, positive material test, and visual inspection. Third parties also rate our quality testing for assured quality.
Packaging-
Low Temp. Carbon Steel Welded Pipes are packed in the special packing of wooden
boxes, crates, pallets, and cases with coatings of the plastic film adding oxidation
resistance. Ready to learn more For more information
about Low Temperature CS Seamless Pipes, contact Preston Pipes and Alloys today to speak
to an expert.
Grade :
Size Range :
Outer Dimensions :
Wall Thickness :
Length :
Type :
Schedules :
Form :
Grade 1, Grade 3, Grade 4, Grade 6, Grade 7, Grade 8, Grade 9, Grade 10, Grade 11
1/2" NB to 36" NB
19.05mm – 114.3mm
2.0mm – 14 mm
max 16000mm, Single Random, Double Random & Cut Length or As per customer's requirement
Seamless / ERW / Welded / Fabricated / LSAW Pipes
SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules
SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH120, SCH140, SCH160, XXS
Round Pipes, Square Pipes, Rectangular Pipe
| Grades | C, max | Mn | P, max | S, max | Si | Ni | Cr | Cu | Al | Va | Co | Mo | cb |
| Gr.1 | 0.30 | 0.40–1.06 | 0.025 | 0.025 | - | - | - | - | - | - | - | - | - |
| Gr.3 | 0.19 | 0.31–0.64 | 0.025 | 0.18–0.37 | 3.18–3.82 | - | - | - | - | - | - | - | - |
| Gr.4 | 0.12 | 0.50–1.05 | 0.025 | 0.025 | 0.08–0.37 | .47–0.98 | 0.44–1.01 | 0.40–0.75 | 0.04–0.30 | - | - | - | - |
| Gr.6 | 0.30 | 0.29–1.06 | 0.025 | 0.025 | 0.10 min | - | - | - | - | - | - | - | - |
| Gr.7 | 0.19 | 0.90 max | 0.025 | 0.025 | .13–0.32 | .03–2.57 | - | - | - | - | - | - | - |
| Gr.8 | 0.13 | 0.90 max | 0.025 | 0.025 | 0.13–0.32 | 8.40–9.60 | - | - | - | - | - | - | - |
| Gr.9 | 0.20 | 0.40–1.06 | 0.025 | 0.025 | - | 1.60–2.24 | - | 0.75–1.25 | - | - | - | - | - |
| Gr.10 | 0.20 | 1.15–1.50 | 0.035 | 0.015 | 0.10–0.35 | 0.25 max | 0.15 max | 0.15 max | 0.06 max | 0.12 | 00.05 | 0.05 | - |
| Gr.11 | 0.10 | 0.60 max | 0.025 | 0.025 | 0.35 max | 35.0–37.0 | 0.50 max | - | - | - | - | 0.50 max | 0.50 max |
| Properties | ||||
| Grades | Yield strength(min) | Tensile strength(min) | Elongation(%, min) Y | Elongation(%, min) X |
| Gr.1 | 205Mpa | 380Mpa | 35 | - |
| Gr.3 | 450 Mpa | 240 Mpa | 30 | 20 |
| Gr.4 | 415 Mpa | 240 Mpa | 30 | 16.5 |
| Gr.6 | 0.30 | 0.29–1.06 | 0.025 | 0.025 |
| Gr.7 | 450 Mpa | 240 Mpa | 30/16.5 | - |
| Gr.8 | 100 000 | 75 000 | - | |
| Gr.9 | 450Mpa | 240 Mpa | 30/16.5 | - |
| Gr.10 | ≥550Mpa | ≥450Mpa | ≥22 | - |
| Gr.11 | 450mpa | 240Mpa | 18A | - |
Low Temperature Carbon
Steel Pipe
ASTM A333 Grade 1 LTCS Pipes
Low Temperature Carbon Steel Gr 3 Pipes
Low Temp. Carbon Steel Gr.4 Seamless Pipes
Grade 7 Low-Temperature Carbon Steel Pipe
ASTM A333 LTCS Grade 8 Seamless Pipe
ASME SA 333 Carbon Steel Gr.9 Welded Pipes
Carbon Steel Gr.10 Welded Pipe Supplier
LTCS Grade 11 ERW Pipes Exporter
Gr 1 Low Temp. Carbon Steel Seamless Pipes
ASTM A333 Carbon Steel Gr.3 Welded Pipe
Low Temp. Pipe Equivalent
Grades
Low Temperature Black Steel Pipe
Low Temperature Carbon Steel Hot-Dipped Galvanized Pipe
Low Temperature Seamless Carbon Steel Pipe
LTCS Zinc-Coated Steel Pipes
Carbon Steel Submerged Arc Welded Pipes
Low Temperature Carbon Steel Seamless Pipes
LTCS Longitudinally Submerged Arc Welded Pipes
Industrial Low Temp. Carbon Steel Pipe
Low Temperature Carbon Steel Seamless Pipes
Low Temp. Carbon Steel Pipes
Low Temperature Carbon Steel Seamless Pipes are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of ASTM A333 LTCS Welded Pipes, Welded Pipes through a worldwide network of stock-keeping branches. These are use in various industries like :
- Chemical Industry
- Oil & Gas Industry
- Petrochemical Industry
- Power Genration Industry
- Sugar Industry
- Food Processing Industry
- Paper & Pulp Industry
- Offshore and Onshore Services
