Stainless Steel 310 Sheet and 310S stainless steel sheet are high-alloy austenitic stainless steel grades, which are known for excellent resistance to oxidation, corrosion, and scaling at high temperatures. The high chromium and nickel content provides superior strength, durability, and stability even under extreme heat conditions. Stainless steel 310 plate and 310S stainless steel plate are often used in furnaces, heat exchangers, kilns, and other high-temperature environments. As 310S contains a lower carbon content, it reduces the risk of welding sensitisation and intergranular corrosion. Stainless steel 310, and 310S coils offer high strength, good formability, and excellent weldability, which makes them suitable for demanding industrial applications. Both grades have a maximum Rockwell B hardness of 95, along with mechanical properties including 40% elongation, 205 MPa yield strength, and 515 MPa tensile strength. Preston Pipes and Alloys supplies these products in a wide range of sizes and forms to meet diverse industry requirements.
Up to operating temperatures of 1050°C for Stainless Steel 310 and 1150°C for Stainless Steel 310S, these grades perform reliably in continuous high-temperature service. At lower temperatures, they resist wet corrosion well and can endure exposure to a wide range of organic and inorganic chemicals. Weldability is outstanding, as 310S provides enhanced protection against intergranular corrosion after welding. At high temperatures, both classes maintain their strength and ductility, even at cryogenic temperatures, as they retain their resilience. Furnace components, burners, heat exchangers, furnaces, catalytic recovery systems, and tube hangers have various applications within the petroleum refining industry. They are also widely used in chemical processing plants, coal gasifiers, food processing equipment, and cryogenic systems. Industries such as aerospace, power generation, and electronics rely on stainless steel 310 and 310S for long service life, low maintenance, and dependable performance under stress.
Stainless Steel 310/310S sheets, plates, and coils are manufactured in accordance with ASTM A240 and ASME SA240 standards. Available thicknesses range from 0.3 mm to 120 mm, with widths from 1000 mm to 3500 mm and lengths between 2000 mm and 6000 mm. Surface finishes include 2B, BA, No. 1, No. 4, mirror finish, checkered, embossed, hairline, and other customised options. Production involves electric arc furnace melting and casting, followed by hot rolling, optional cold rolling, and surface treatments such as annealing, pickling, and polishing. These materials can be forged at temperatures ranging from 975°C to 1175°C, welded using conventional welding procedures, and cold-formed with ease. To control work hardening, machine operators require sharp tools and sufficient lubrication.
Each batch undergoes tensile, hardness, flattening, and flaring testing to verify mechanical integrity. Positive Material Identification (PMI) certifies the right chemical composition, whereas corrosion, pitting and intergranular corrosion tests verify service performance. Dimensional accuracy is checked for every order. Packaging includes waterproof covering, wooden crates and clear labels to keep things safe while they are being handled and shipped. Plates and coils are safely bundled together, although sheets can be sleeved one at a time. One can choose custom packaging options, such as extra weather protection for goods going abroad. Call us today for the most up-to-date prices for stainless steel 310 sheets, SS 310 plates and SS 310 plates in Mumbai, India, and the cost per kg for SS 310 plates. We can also give you complete specifications as per the project requirement.
310 Stainless Steel Coil and Foil Suppliers with Mirror and Brushed Surface Finish
| Specifications | ASTM A240 / ASME SA240 |
| Thickness | 4mm-100mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed,
hair line, sand blast, Brush, etching, etc |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
ASTM A240 Type 310 Chequered Plate, UNS S31008 Perforated Sheet at Factory Price
| Materials | Grades | Price in Kg (₹) | |
| Plates | |||
| Stainless Steel | 310 | 599-700 | |
| 3/16" | 1/4" | 5/16" | 3/8" | 1/2" | 5/8" | 3/4" | 1" |
| 4.8mm | 6.3mm | 7.9mm | 9.5mm | 12.7mm | 15.9mm | 19mm | 25.4mm |
| 1 1/4" | 1 1/2" | 1 3/4" | 2" | 2 1/4" | 2 1/2" | 3" | |
| 31.8mm | 38.1mm | 44.5mm | 50.8mm | 57.2mm | 63.5mm | 76.2mm |
| Size(mm) | Weight (Kg) |
| 4000 x 2000 x 5.0 | 340.0 |
| 4000 x 2000 x 6.0 | 408.0 |
| 2500 x 1250 x 6.0 | 159.0 |
| 4000 x 2000 x 2.0 | 136.0 |
| 3000 x 1500 x 5.0 | 191.0 |
| 4000 x 2000 x 3.0 | 204.0 |
| 4000 x 2000 x 4.0 | 272.0 |
| 3000 x 1500 x 6.0 | 230.0 |
| 3000 x 1500 x 4.0 | 153.0 |
| 2500 x 1250 x 4.0 | 106.0 |
| Size (mm) | 4000 x 2000 x 3.0 | 2500 x 1250 x 4.0 | 3000 x 1500 x 4.0 | 4000 x 2000 x 4.0 |
| Weight per plate (Kg) | 204 | 106 | 153 | 272 |
| Thickness (mm) | 0.031-0.041 (0.79-1.04) | 0.017-0.030 (0.43-0.76) | 0.042-0.059 (1.1-1.5) | 0.132-0.146 (3.4-3.7) | 0.074-0.084 (1.9-2.1) | 0.060-0.073 (1.5-1.9) | 0.100-0.115 (2.5-2.9) | 0.085-0.099 (2.2-2.5) | 0.116-0.131 (2.9-3.3) | 0.147-0.187 (3.7-4.7) |
| Sheet Width (mm) | 0.003 (0.076) | 0.002 (0.051) | 0.004 (0.10) | 0.009 (0.23) | 0.0055 (0.14) | 0.0045 (0.11) | 0.007 (0.18) | 0.006 (0.15) | 0.0075 (0.19) | 0.0105 (0.2) |
| 0.002 (0.051) | 0.0015 (0.038) | 0.003 (0.076) | 0.006 (0.15) | 0.004 (0.10) | 0.003 (0.076) | 0.005 (0.13) | 0.004 (0.10) | 0.005 (0.13) | 0.007 (0.18) |
- NO.8
- NO.4
- Sand Blast
- Mirror Finish
- NO.1
- Brush
- Checkered
- 2B
- Embossed
- Etching
- BA
- 2D
- Brushed Finish
- 8K
- Hair line
Stainless Steel 310 Sheet Metal
ASTM A240 Type 310 Perforated Sheet
310 Stainless Chequered Plate
Stainless 310 Plain Sheet
WNR 1.4841 Cold Rolled Sheet
UNS S31000 Hot Rolled Plate
SUS 310 Strip
AISI 310 Coil
310 SS Foil
INOX 310 Shim Sheet
SS 310 Shim Stock
Get an instant quote for SS 310 plate price and place your order today.
| Element Alloy | Present % | |||
| TS | L | C, H, P | TW | |
| Carbon | 0.08 | 0.08 | 0.08 | 0.08 |
| Silicon | 1.00 | 1.00 | 1.00 | 1.00 |
| Manganese | 2.00 | 2.00 | 2.00 | 2.00 |
| Phosphorous | 0.040 | 0.045 | 0.045 | 0.0453 |
| Sulfur | 0.0151 | 0.0301 | 0.0151 | 0.0153 |
| Chromium | 16.50 - 18.50 | 16.50 - 18.50 | 16.50 - 18.50 | 16.50 - 18.50 |
| Nickel | 10.50 - 13.502 | 10.50 - 13.502 | 10.50 - 13.50 | 10.50 - 13.50 |
| Molybdenum | 2.00 - 2.50 | 2.00 - 2.50 | 2.00 - 2.50 | 2.00 - 2.50 |
| Titanium | 5xC to 070 | 5xC to 070 | 5xC to 070 | 5xC to 070 |
| Iron , Fe | Balance | Balance | Balance | Balance |
|
0.2% Offset |
Strength |
in 2 in. |
|
||
| psi (min.) | (MPa) | psi (min.) | (MPa) | % (min.) | (max.) |
| 35,000 | 245 | 80,000 | 550 | 45 | 217 Brinell |
| Property | Imperial Units | Metric Units |
| Density | 0.285 lbs/in³ | 7.89 g/cm³ |
| Specific Heat | 0.12 BTU/lb-°F (32–212°F) | 502 J/kg-°K (0–100°C) |
| Modulus of Elasticity | 28.5 × 10⁶ psi | 196 GPa |
| Thermal Conductivity (at 212°F / 100°C) | 8.0 BTU/hr·ft²·ft·°F | 10.8 W/m·°K |
| Melting Range | 2470 – 2555°F | 1354 – 1402°C |
| Electrical Resistivity | 30.7 microhm-in at 68°F | 78.0 microhm-cm at 20°C |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | EN |
| SS 310 | 1.4841 | S31000 | SUS 310 | 310S24 | 20Ch25N20S2 | X15CrNi25-20 |
| SS 310S | 1.4845 | S31008 | SUS 310S | 310S16 | 20Ch23N18 | X8CrNi25-21 |
SS 316Ti Shim Sheet available in Custom Finish, Size and Thickness
- Material TC as per EN 10204 3.2, EN 10204 3.1 standards
- TC certified NACE MR0103, NACE MR0175
- Raw material TC
- QAP
- Heat treatment information
- Packing notes
Stainless Steel 310 Plate Packing
- Carton box
- Wooden pallets
- Shrink wrapped
- Wooden crates
- Wooden box
- Steel Strapping
- Custom
Stainless Steel 310 Plate Testing Methods
- Flattening test
- PMI test
- Hardness test
- Ultrasonic test
- Radiography test
- Flaring test
- Eddy current test
- Impact test
- Bend test
- IGC test
- Macro and micro test
- Hydrostatic test
SS 310 Plate Features
- High Temperature Resistance
- Excellent Oxidation Resistance
- Corrosion Resistance
- Non-magnetic
- Superior Weldability
Stainless 310S Plate Cutting Service
- Plasma Cutting
- Laser cutting
- Oxy propane flame cutting
Stainless Steel 310 plates contain high levels of chromium and nickel, which provide excellent oxidation resistance and structural strength at temperatures up to 1050°C. These elements form a protective oxide layer that inhibits scaling and ensures durability under intense heat stress.
Compared to SS 304 and SS 316, which are standard corrosion-resistant grades, SS 310 offers superior heat resistance and higher creep strength. It withstands elevated temperatures without losing mechanical properties or suffering rapid oxidation.
SS 310 plates are widely used in thermal processing, chemical production, and power generation industries. Common applications include furnace manufacturing, heat treatment plants, hydrocarbon refining, kilns, and catalytic recovery systems.
Standard SS 310 plates are available in thicknesses ranging from 4 mm to 100 mm. Typical widths range from 1000 mm to 3500 mm, and lengths from 2000 mm to 6000 mm, with custom sizes available for specific project requirements.
SS 310 offers excellent resistance to carburising and reducing furnace environments. It also withstands intergranular corrosion, especially in the low-carbon 310S variant. This stability prevents cracking during repeated high-temperature heating cycles.
