ASTM A240 904L Stainless Steel Sheet and Plate Supplier in Mumbai, India
Table of Content
Preston Pipes & Alloys stands as a leading provider of stainless steel 904L sheets, plates, and coils. These products offer excellent resistance to oxidation, corrosion, and acidic environments, making them a trusted choice across many industries. The stainless steel 904L sheets, plates, and coils combine strong mechanical properties with a carefully balanced chemical composition. This grade contains elements like chromium, molybdenum, nickel, and copper that help improve durability and corrosion resistance. The material has excellent yield strength, tensile strength, and elongation, ensuring reliable performance in demanding conditions. As a leading 904L stainless steel plate suppliers, Preston Alloys delivers quality products for various uses.
904L stainless steel sheets, and plates have high resistance, and strength in aggressive environments. These properties make them appropriate to be utilized in chemical processing, metal industries, petroleum and gas production, and air pollution control. The pharmaceutical industry also benefits from the corrosion resistant and clean surface of such materials. Stainless steel 904L is well suited to pulp and paper processing and is appropriate for seawater and brackish water conditions. The durability, and versatility of stainless steel 904L plates make sure it meets the strict industry requirements for long, and safe operations.
The specifications of stainless steel 904L products vary to fit customer requirements. The thickness ranges from very thin sheets that are 0.025 mm thick to plates that are 3 mm thick. Width might be as little as 3 mm wide strips, or 2000 mm coils. Length options include standard sizes like 2000 mm, 2440 mm, 3000 mm, 5800 mm, and 6000 mm. These products meet several standards, such as JIS, AISI, ASTM, GB, DIN and EN. Surface finish options include sand blast, brush and etching, enabling customized options according to particular requirements. The production process assures uniform quality in all diameters of ss 904L plates, and 904L stainless steel coils.
Each lot goes through extensive quality inspections and tests for material integrity and performance. Packaging is of high quality to secure products in transit. Products are shipped safely packed in wooden crates, plastic wraps or strapped, with steel strips, as requested by the customers. Such attention ensures suppliers of ss 904L sheet send products that reach in ideal condition and are immediate use.
UNS N08904 Checker Plate With Different Sizes and Thickness
| Specifications | ASTM A240 / ASME SA240 |
| Thickness | 4mm-100mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
Stainless Steel 904L Perforated Sheet, SS WNR 1.4539 Coil in Hot and Cold Rolled Forms
| Materials | Grades | Price in Kg (₹) | |
| Plates | |||
| Stainless Steel | 904L | 750-1200 | |
| Size | Weight (per sheet) | Weight (per Sq. ft.) |
| 11 ga. (.120″) * 60 * 96 | 252.0 | 5.040 |
| 12 ga. (.105″) * 36 * 120 | 132.3 | 4.410 |
| 14 ga. (.075″) * 48 * 120 | 126.0 | 3.150 |
| 16 ga. (.060″) * 36 * 120 | 75.60 | 2.520 |
| 11 ga. (.120″) * 36 * 120 | 151.2 | 5.040 |
| 11 ga. (.120″) * 48 * 96 | 161.3 | 5.040 |
| 22 ga. (.030″) * 36 * 120 | 37.80 | 1.260 |
| 12 ga. (.105″) * 60 * 120 | 220.5 | 4.410 |
| 14 ga. (.075″) * 36 * 120 | 94.50 | 3.150 |
| 18 ga. (.048″) * 48 * 120 | 80.64 | 2.016 |
| 20 ga. (.036″) * 36 * 120 | 45.36 | 1.512 |
| 20 ga. (.036″) * 48 * 120 | 60.48 | 1.512 |
| 16 ga. (.060″) * 48 * 96 | 80.64 | 2.520 |
| 7 ga. (.1874″) * 48 * 120 | 314.8 | 7.871 |
| 11 ga. (.120″) * 48 * 120 | 201.6 | 5.040 |
| 11 ga. (.120″) * 48 * 144 | 241.9 | 5.040 |
| 18 ga. (.048″) * 36 * 120 | 60.48 | 2.016 |
| 10 ga. (.135″) * 48 * 120 | 226.8 | 5.670 |
| 22 ga. (.030″) * 48 * 96 | 40.32 | 1.260 |
| 3/16" | 1/4" | 3/8" | 1/2" | 5/8" | 3/4" |
| 4.8mm | 6.3mm | 9.5mm | 12.7mm | 15.9mm | 19mm |
| 1" | 1 1/4" | 1 1/2" | 1 3/4" | 2" | |
| 25.4mm | 31.8mm | 38.1mm | 44.5mm | 50.8mm |
| Sheet Weight (lbs/in²) | Thickness (inches) |
| 0.391² | 1 1/4 |
| 0.06000 | 3/16 |
| 0.47 | 1 1/2 |
| 0.549 | 1 3/4 |
| 0.196 | 5/8 |
| 0.235 | 3/4 |
| 0.274 | 7/8 |
| 0.313 | 1 |
| 0.784 | 2 1/2 |
| 0.862 | 2 3/4 |
| 0.941 | 3 |
| 0.627 | 2 |
| 0.705 | 2 1/4 |
| 0.08 | 1/4 |
| 0.121 | 3/8 |
| 0.161 | 1/2 |
| Width (mm) | Thickness (mm) | Surface Finish |
| max. 2032 | 0.25–8.0 | 2B – Cold rolled, heat treated, pickled, skin passed |
| max. 1524 | 0.4–6.35 | 2D – Cold rolled, heat treated, pickled |
| max. 2032 | 0.4–8.0 | 2E – Cold rolled, heat treated, mechanically descaled |
| max. 1524 | 0.25–3.5 | 2R – Cold rolled, bright annealed |
| max. 1524 | 0.4–6.35 | 2H – Work hardened |
| max. 1524 | 0.5–4.0 | Polished, brushed |
- NO.8
- NO.4
- Sand Blast
- Mirror Finish
- NO.1
- Brush
- Checkered
- 2B
- Embossed
- Etching
- BA
- 2D
- Brushed Finish
- 8K
- Hair line
Stainless Steel 904L Sheet Metal
ASTM A240 Type 904L Perforated Sheet
SS 904L Chequered Plate
Stainless 904L Plain Sheet
SS 904L Cold Rolled Sheet
UNS N08904 Hot Rolled Plate
SUS 904L Strip
AISI 904L Coil
904L SS Foil
INOX 904L Shim Sheet
SS 904L Shim Stock
Get Stainless Steel 904L Plates in stock – Place your order today!
| Nickel | 23.0 min.-28.0 max. | Silicon | 1.00 |
| Chromium | 19.0 min.-23.0 max. | Phosphorus | 0.045 |
| Molybdenum | 4.0 min.-5.0 max. | Sulfur | 0.035 |
| Copper | 1.0-2.0 max. | Iron | Balance |
| Manganese | 2.00 |
|
0.2% Offset |
Strength |
in 2 in. |
|
||
| psi (min.) | (MPa) | psi (min.) | (MPa) | % (min.) | (max.) |
| 31,000 | 220 | 71,000 | 490 | 36 | 70-90 Rockwell B |
| Property | Imperial | Metric |
| Density | 0.287 lbs/in³ | 7.95 g/cm³ |
| Specific Heat | 0.11 BTU/lb-°F (32–212°F) | 450 J/kg-K (0–100°C) |
| Modulus of Elasticity | 28.0 × 10⁶ psi | 190 GPa |
| Thermal Conductivity at 212°F (100°C) |
6.8 BTU/Ft-hr°F | 12.9 W/m-K |
| Melting Range | 2372–2534°F | 1300–1390°C |
| Electrical Resistivity | 33.5 µΩ-in at 68°C | 95.2 µΩ-cm at 20°C |
| STANDARD | UNS | WERKSTOFF NR. | EN | JIS | KS | BS | AFNOR |
| ASTM A240 gr 904L plate | N08904 | 1.4539 | X1NiCrMoCu25-20-5 | SUS 904L | STS 317J5 | 904S13 | Z2 NCDU 25-20 |
Buy Bulk Stock of Stainless Steel 904L Coil and Foil at Affordable Price
904L Stainless Steel Plate documents
- Material TC as per EN 10204 3.2, EN 10204 3.1 standards
- TC certified NACE MR0103, NACE MR0175
- Raw material TC
- QAP
- Heat treatment information
- Packing notes
Stainless Steel 904L Sheet Packing
- Carton box
- Wooden pallets
- Shrink wrapped
- Wooden crates
- Wooden box
- Steel Strapping
- Custom
Stainless Steel 904L Plate Testing Methods
- Flattening test
- PMI test
- Hardness test
- Ultrasonic test
- Radiography test
- Flaring test
- Eddy current test
- Impact test
- Bend test
- IGC test
- Macro and micro test
- Hydrostatic test
SS 904L Plate Characteristics
- Super Austenitic Composition
- Corrosion Resistance
- Temperature Resistance
- Low Carbon Content
- Resistance to Oxidation
- High Alloy Stability
Stainless 904L Plate Cutting Service
- Plasma cutting
- Laser cutting
- Oxy propane flame cutting
