Stainless Steel 446 Sheet, Plate, and
Coil are premium ferritic stainless steel materials intended for high-temperature
oxidation, and corrosion resistance. Known for their hardness and heat resistance, they
are commonly used in harsh industrial applications. Preston Pipes & Alloys, a
reputed
name among SS 446 Sheet Suppliers, provides superior quality products in accordance with
international standards. These coils, sheets, and plates are used in industries like oil
and gas, petrochemical, chemical, power generation, energy, pharmaceutical, pulp and
paper, food processing, aerospace, and refining, as they are strong and work well in
tough conditions.
AISI 446 stainless steel contains a high level of chromium, along with carbon,
manganese, nitrogen, silicon, nickel, phosphorus, sulfur, and iron as the balance. This
composition gives the alloy excellent scaling resistance and stability at elevated
temperatures. With a density of 7.5 g/cm³, a yield strength of 40,000 psi (275 MPa) and
a tensile strength of 75,000 psi (485 MPa), the material provides strong mechanical
performance. It has an elongation of 20% and a melting point of 1510°C (2750°F), which
allows it to be used in high-heat applications without deteriorating its structure.
These qualities make it a reliable choice for industries that demand both mechanical
strength and chemical resistance, which is why many trust aisi 446 Stainless Steel Plate
Suppliers for consistent quality.
Stainless 446 Plate, Stainless Steel 446 Coil, and related products are available in a
wide range of specifications. Thickness ranges from 4 mm to 100 mm, widths from 1000 mm
to 3500 mm, and lengths from 2000 mm to 6000 mm. Surface finishes include 2B, 2D, BA,
No.1, No.4, No.8, mirror, checkered, embossed, hairline, sandblast, brushed, and etched.
Finishes are offered in hot rolled, cold rolled, satin, and other types, often with
protective plastic coating. Forms include coils, foils, rolls, plain sheets, shim
sheets, perforated sheets, chequered plates, strips, flats, blanks, and rings.
Customized dimensions are also available to meet unique project needs.
Each Stainless Steel 446 Sheet goes through extensive quality testing, including
mechanical, and chemical tests, to make sure it meets standards. To ensure that products
are safe while they are being shipped, it is packed in wooden boxes, plastic wraps or
bundles with steel straps. From the manufacturing process to the final installation
site, careful inspection and secure packaging maintain the product in good condition.
For high-quality stainless steel materials that deliver performance and reliability,
choose the right grade and finish to match your industrial requirements
Specification of
446 Stainless Steel Sheet
| Specifications |
ASTM A240 / ASME SA240 |
| Thickness |
4mm-100mm |
| Width |
1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm,
etc |
| Length |
2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface |
2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed,
hair line, sand blast, Brush, etching, etc |
| Finish |
Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8),
SATIN (Met with Plastic Coated) |
| Form |
Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet,
Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange)
etc. |
Stainless Steel 446
Plate Price Range
| Materials |
Grades |
Price in Kg (₹) |
| Plates |
Stainless Steel 446 |
270-300 |
ASTM A240 Type 446
Sheet Weight Chart
| Size (mm) |
Weight per (Kg) |
Size (mm) |
Weight per (Kg) |
| 4000 * 2000 * 2.0 |
136.0 |
3000 * 1500 * 5.0 |
191.0 |
| 4000 * 2000 * 3.0 |
204.0 |
4000 * 2000 * 5.0 |
340.0 |
| 2500 * 1250 * 4.0 |
106.0 |
2500 * 1250 * 6.0 |
159.0 |
| 3000 * 1500 * 4.0 |
153.0 |
3000 * 1500 * 6.0 |
230.0 |
| 4000 * 2000 * 4.0 |
272.0 |
4000 * 2000 * 6.0 |
408.0 |
| 2500 * 1250 * 5.0 |
133.0 |
|
|
Gauge Chart of SA 240
SS 446 Plate
| Gauge |
LB/Sq. Ft. |
LB/Sq In. |
Gauge Tolerance |
| 72″ Wide |
96″ Wide |
| 3/16 |
0.1875 |
8.579 |
0.05958 |
+.045″ -.010″ |
+.050″ -.010″ |
| 7/32 |
0.2187 |
9.870 |
0.06854 |
| 1/4 |
0.2500 |
11.162 |
0.07750 |
| 5/16 |
0.3125 |
13.746 |
0.09546 |
| 3/8 |
0.3750 |
16.496 |
0.11456 |
+.055″ -.010″ |
+.060″ -.010″ |
| 7/16 |
0.4375 |
19.080 |
0.13250 |
| 1/2 |
0.5000 |
21.633 |
0.15044 |
| 9/16 |
0.5625 |
24.247 |
0.16838 |
| 5/8 |
0.6250 |
26.831 |
0.18633 |
| 11/16 |
0.6875 |
29.415 |
0.20427 |
| 3/4 |
0.7500 |
32.123 |
0.22308 |
+.060″ -.010″ |
+.065″ -.010″ |
| 13/16 |
0.8125 |
34.707 |
0.24102 |
| 7/8 |
0.8750 |
37.291 |
0.25897 |
| 15/16 |
0.9375 |
39.875 |
0.27691 |
| 1 |
1.0000 |
42.665 |
0.29628 |
+.070″ -.010″ |
+.075″ -.010″ |
| 1-1/8 |
1.1250 |
47.833 |
0.33217 |
| 1-1/4 |
1.2500 |
53.001 |
0.36806 |
| 1-3/8 |
1.3750 |
58.169 |
0.40395 |
| 1-1/2 |
1.5000 |
63.337 |
0.43984 |
| 1-3/4 |
1.7500 |
73.672 |
0.51161 |
| 2 |
2.0000 |
84.008 |
0.58339 |
+.125″ -.010″ |
+.150″ -.010″ |
| 2-1/8 |
2.1250 |
89.610 |
0.62229 |
| 2-1/4 |
2.2500 |
94.777 |
0.65817 |
| 2-1/2 |
2.5000 |
105.113 |
0.72995 |
| 2-3/4 |
2.7500 |
115.449 |
0.80173 |
| 3 |
3.0000 |
126.301 |
0.87709 |
+.150″ -.010″ |
+.160″ -.010″ |
| 3-1/2 |
3.5000 |
146.972 |
1.02064 |
| 4 |
4.0000 |
168.264 |
1.16850 |
+.180″ -.010″ |
+.200″ -.010″ |
SUS 446 Plate
Thickness Chart
| Thickness (Inch) |
2.3 |
3.2 |
4.5 |
6 |
9 |
12 |
16 |
19 |
22 |
| Weight (kg/m²) |
19.73 |
26.79 |
36.99 |
48.77 |
72.32 |
95.87 |
127.3 |
150.9 |
174.4 |
| 914 × 1,829 |
three * six |
33 |
44.8 |
61.8 |
81.5 |
121 |
160 |
213 |
252 |
292 |
| 1,219 × 2,438 |
(4 × 8) |
58.6 |
79.6 |
110 |
145 |
215 |
285 |
378 |
448 |
518 |
| 1,524 × 3,048 |
(5 × 10) |
- |
125 |
172 |
227 |
336 |
445 |
591 |
701 |
810 |
UNS S44600 Strip Size
Chart
| Size (mm) |
2500 × 1250 |
2000 × 1000 |
3000 × 1500 |
| 1.2 |
30 |
20 |
43 |
| 0.9 |
22.5 |
14.4 |
- |
| 2 |
50 |
32 |
72 |
| 1.5 |
37.5 |
24 |
54 |
| 4 |
100 |
64 |
144 |
| 3 |
79 |
50 |
113 |
| 5 |
132 |
84 |
189 |
Stainless
Steel 446 Plate Surface Finishes
- NO.8
- NO.4
- Sand Blast
- Mirror Finish
- NO.1
- Brush
- Checkered
- 2B
- Embossed
- Etching
- BA
- 2D
- Brushed Finish
- 8K
- Hair line
Stainless Steel
446 Plate Types
Stainless Steel 446 Sheet Metal
ASTM A240 Type 446 Perforated Sheet
SS 446 Chequered Plate
Stainless 446 Plain Sheet
WNR 1.4762 Cold Rolled Sheet
UNS S44600 Hot Rolled Plate
SUS 446 Strip
AISI 446 Coil
446 SS Foil
INOX 446 Shim Sheet
SS 446 Shim Stock
Get high-heat resistant Stainless Steel 446 Plates
Chemical Composition of Stainless 446 Sheet
& Plate
| Element |
Content (%) |
| Iron, Fe |
73 |
| Chromium, Cr |
23.0 - 27.0 |
| Manganese, Mn |
1.50 |
| Silicon, Si |
1.0 |
| Nickel, Ni |
0.25 |
| Carbon, C |
0.20 |
| Phosphorous, P |
0.040 |
| Sulfur, S |
0.030 |
Mechanical
Properties of ASTM A240 Type 446 Plate
| Properties |
Metric |
Imperial |
| Tensile strength |
550 MPa |
79800 psi |
| Yield strength (@strain 0.200%) |
345 MPa |
50000 psi |
| Elastic modulus |
200 GPa |
29000 ksi |
| Poisson's ratio |
0.27-0.30 |
0.27-0.30 |
| Elongation at break |
20% |
20% |
| Hardness, Brinell (estimated from Rockwell B) |
159 |
159 |
| Hardness, Knoop (estimated from Rockwell B) |
173 |
173 |
| Hardness, Rockwell A (estimated from Rockwell B) |
51.1 |
51.1 |
| Hardness, Rockwell B |
83 |
83 |
| Hardness, Vickers (estimated from Rockwell B) |
159 |
159 |
Physical Properties of 446 Stainless Steel Sheet
| Properties |
Metric |
Imperial |
| Density |
7.80 g/cm3 |
0.282 lb/in³ |
Equivalent Material of AISI 446 Plate
| STANDARD |
WERKSTOFF NR. |
UNS |
AISI / SAE |
| SS 446 |
1.4762 |
S44600 |
446 |
446 Stainless Steel Plate
documents
- Material TC as per
EN 10204 3.2, EN 10204 3.1 standards
- TC certified NACE
MR0103, NACE MR0175
- Raw material TC
- QAP
- Heat treatment
information
- Packing notes
Stainless Steel
446 Sheet Packing
- Carton box
- Wooden pallets
- Shrink wrapped
- Wooden crates
- Wooden box
- Steel Strapping
- Custom
Stainless Steel
446 Plate Testing Methods
- Flattening test
- PMI test
- Hardness test
- Ultrasonic test
- Radiography test
- Flaring test
- Eddy current test
- Impact test
- Bend test
- IGC test
- Macro and micro test
- Hydrostatic test
SS 446 Plate
Characteristics
- High Chromium
Content
- Corrosion Resistance
- Heat Resistance
- Oxidation Resistance
- Cost-Effective
Stainless 446
Plate Cutting Service
- Plasma cutting
- Laser cutting
- Oxy propane flame
cutting
Industrial
Application of Stainless Steel 446 Sheet, Plate, Coil
