ASTM A240 SS 347H Sheet Stockist, 347H Stainless Steel Plate Supplier in Mumbai, India
Table of Content
Stainless Steel 347H sheet, plate, and coil are high-temperature, corrosion-resistant materials made with added columbium to enhance stability. These products deliver excellent strength at elevated temperatures and resist intergranular corrosion. SS 347H sheets are outstanding for challenging operations, as it won't rust easily in corrosive environments. These plates consist of chromium, nickel, carbon, manganese, silicon, phosphorus, sulfur, columbium, and iron, as it provide long-term durability along with robust mechanical properties. Preston Pipes & Alloys is a leading manufacturer and seller of stainless steel 347H sheet, plate, and coil. It ensures that the products are exact and satisfy global quality standards, and it works well in various applications.
ASTM A240 TP347H Stainless Steel Plates possess high strength, thermal stability and chemical mix resistance. It performs impressively in environments where constant exposure to heat and corrosive agents is common. These properties make them valuable in the petrochemical, oil and gas, chemical, power plant, and energy industries. These plates are also used in the aerospace, pharmaceuticals, pulp and paper, and food processing industries. As it can handle a lot of pressure and harsh conditions, which makes them a reliable choice for crucial operations.
Stainless Steel 347H Sheets, plates, and coils are offered in different specifications to suit various requirements. The standards include ASME SA240 and ASTM A240, and the dimensions are available in ASTM, ASME, and API specifications. The widths vary between 1000 mm and 3500 mm, the thickness from 4 mm up to 100 mm, and the lengths from 2000 mm to 6000 mm. The surface finishes are sandblasted, etched, brushed, hot-rolled, and cold-rolled. We offer coils, foils, rolls, plain sheets, shim sheets and perforated sheets, and it is available in any size as per the requirement of the project. This adaptability ensures, that it can handle a wide range of installation and production methods.
Each stainless steel 347H plate, sheet, and coil undergoes rigorous quality inspections such as mechanical testing, chemical testing, and dimension testing. By using wooden cases, plastic wrapping, steel strip bundles or specially designed packages based on project requirements, secure packaging protects the material from damage during handling and transit. When we properly prioritize quality and safe delivery, the material arrives at the location in ideal condition. For reliable stainless steel 347H plates, get in touch, with us right now.
UNS S34709 Checker Plate, AISI 347H Perforated Sheet, 347H SS Coil and Foil with Range Of Sizes
| Specifications | ASTM A240 / ASME SA240 |
| Thickness | 4mm-100mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
ASME SA 240 347H Stainless Steel Strip, WNR 1.4961 Shim Stock at Lowest Price
| Materials | Grades | Price in Kg (₹) | |
| Plates | |||
| Stainless Steel | 347H | 350-400 | |
| 3/16" | 1/4" | 5/16" | 3/8" | 1/2" | 5/8" | 3/4" | 7/8" | 1" | 1 1/8" |
| 4.8mm | 6.3mm | 7.9mm | 9.5mm | 12.7mm | 15.9mm | 19mm | 22.2mm | 25.4mm | 28.6mm |
| 1 1/4" | 1 1/2" | 1 3/4" | 2" | 2 1/4" | 2 1/2" | 2 3/4" | 3" | 3 1/2" | 4" |
| 31.8mm | 38.1mm | 44.5mm | 50.8mm | 57.2mm | 63.5mm | 69.9mm | 76.2mm | 88.9mm | 101.6mm |
| Sizes in mm | Availability |
| 0.4 | √ |
| 0.5 | √ |
| 0.8 | √ |
| 1 | √ |
| 1.2 | √ |
| 1.6 | √ |
| 2 | √ |
| 3 | √ |
| 4 | √ |
| 5 | √ |
| 6 | √ |
| 8 | √ |
| 10 | √ |
| 12 | √ |
| 16 | √ |
| 20 | √ |
| 25 | √ |
| Weight per | sheet (Kg) | 17.9 | 14.7 | 11.5 | 23 | 16.4 | 36.8 |
| Size (mm) | 2500 x1250 x 0.7 | 2000 x1000 x 0.9 | 2000 x1000 x 0.7 | 2500 x1250 x 0.9 | 2000 x1000 x 1.0 | 3000 x1500 x 1.0 | |
| Weight per | sheet (Kg) | 55.3 | 32.7 | 38.4 | 51.2 | 73.7 | 63.9 |
| Size (mm) | 3000 x 1500 x 1.5 | 2000 x 1000 x 2.0 | 2500 x 1250 x 1.5 | 2500 x 1250 x 2.0 | 3000 x 1500 x 2.0 | 2500 x 1250 x 2.5 | |
| Gauge | LB/Sq In. | LB/Sq. Ft. | Tolerance | ||
| 72″ Wide | 96″ Wide | ||||
| 2 | 2.0000 | 84.007 | 0.58337 | +.124″ to .010 | +.150″ to .011″ |
| 2-1/8 | 2.1250 | 89.610 | 0.62228 | ||
| 2-1/4 | 2.2500 | 94.778 | 0.65817 | ||
| 2-1/2 | 2.5000 | 105.113 | 0.72994 | ||
| 2-3/4 | 2.7500 | 115.448 | 0.80173 | ||
| 1 | 1.0000 | 42.665 | 0.29627 | ||
| 1-1/8 | 1.1250 | 47.834 | 0.33216 | +.071″ to .010″ | +.075 to .011″ |
| 1-1/4 | 1.2500 | 53.001 | 0.36806 | ||
| 1-3/8 | 1.3750 | 58.168 | 0.40394 | ||
| 1-1/2 | 1.5000 | 63.336 | 0.43983 | ||
- NO.8
- NO.4
- Sand Blast
- Mirror Finish
- NO.1
- Brush
- Checkered
- 2B
- Embossed
- Etching
- BA
- 2D
- Brushed Finish
- 8K
- Hair line
Stainless Steel 347H Sheet Metal
ASTM A240 Type 347H Perforated Sheet
347H Stainless Chequered Plate
Stainless 347H Plain Sheet
WNR 1.4961 Cold Rolled Sheet
UNS S34709 Hot Rolled Plate
SUS 347H Strip
AISI 347H Coil
347H SS Foil
INOX 347H Shim Sheet
SS 347H Shim Stock
Get high-temperature Stainless Steel 347H Plates – Request your quote today!
| Element | 347H |
| Chromium | 17.00 min.-19.00 max. |
| Nickel | 9.00 min.-13.00 max. |
| Carbon | 0.04 min.-0.10 max. |
| Manganese | 2.00 |
| Phosphorus | 0.045 |
| Sulfur | 0.03 |
| Silicon | 0.75 |
| Columbium & Tantalum | 8 x (C + N) min.-1.00 max. |
| Iron | Balance |
| Yield Strength 0.2% Offset |
Ultimate Tensile Strength |
Elongation in 2 in. |
Hardness | ||
| psi (min.) | (MPa) | psi (min.) | (MPa) | % (min.) | (max.) |
| 30,000 | 205 | 75,000 | 515 | 40 | 201 Brinell |
| Density | 0.288 lbs/in³ | 7.96 g/cm³ |
| Specific Heat | 0.12 BTU/lb-°F (32 – 212°F) | 500 J/kg-°K (0 – 100°C) |
| Modulus of Elasticity | 28.0 × 10⁶ psi | 193 GPa |
| Thermal Conductivity (200°F / 100°C) | 133 BTU/hr/ft²/ft/°F | 16.3 W/m·K |
| Melting Range | 2550 – 2635°F | 1398 – 1446°C |
| Electrical Resistivity | 72 Microhm-cm at 20°F | |
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 347H | 1.4961 | S34709 | SUS 347H | X6CrNiNb18-12 |
Buy Cut to size Stainless Steel 347H Plate at Discounted Price
- Material TC as per EN 10204 3.2, EN 10204 3.1 standards
- TC certified NACE MR0103, NACE MR0175
- Raw material TC
- QAP
- Heat treatment information
- Packing notes
Stainless Steel 347H Plate Packing
- Carton box
- Wooden pallets
- Shrink wrapped
- Wooden crates
- Wooden box
- Steel Strapping
- Custom
Stainless Steel 347H Plate Testing Methods
- Flattening test
- PMI test
- Hardness test
- Ultrasonic test
- Radiography test
- Flaring test
- Eddy current test
- Impact test
- Bend test
- IGC test
- Macro and micro test
- Hydrostatic test
SS 347H Plate Characteristics
- High Carbon Grade
- Corrosion Resistance
- Excellent Heat Resistance
- Oxidation Resistance
- Thermal Stability
Stainless 347H Plate Cutting Service
- Plasma Cutting
- Laser cutting
- Oxy propane flame cutting
